| Nominal Ratings |
| Voltage |
3.3 V |
| Capacity at 23°C Typical (Min) |
1.2 Ah (1.15 Ah) |
| Energy @ 23°C |
3.96 Wh |
| Impedance (1kHz AC) |
<16 mΩ |
| Cycle Life at 1C/1C, 100% DOD |
> 4000 cycles |
| Discharging |
| Max. Continuous Discharge Current |
30A (25C rate) |
| Max. Pulse Discharge Current (10s) |
50A (42C rate) |
| Minimum Voltage / HPPC Pulse |
2 V / 1.6 V |
| Temperature |
-30°C to 60°C |
| Charging |
| Recommended Charge Current |
1.5 A (1C rate) |
| Max. Continuous Charge Current |
4A (3C rate) |
| Max. Pulse Charge Current (10s) |
10A (8C rate) |
| Recommended Charge Voltage |
3.6 V |
| Terminate Charge @ 3.6V |
<50 mA |
| HPPC Pulse Voltage |
3.8 V |
| Float Voltage |
3.5 V |
Temperature Range
(Charging current at <40mA
when under 0 ºC for some applications) |
0 ºC to 60 ºC |
| Storage |
| Storage Temperature |
-40 ºC to 70 ºC |
| Mechanical |
| Diameter |
Ø18.5 +/- 0.1mm |
| Length |
64.95 +/- 0.2mm |
| Mass |
41.5 +/- 1.0g |
| Certifications |
| Transportation |
UN 3480 (UN38.3), CIQ |
| Safety |
UL 1642, IEC 62133-2 |
| Quality System |
ISO-9001, TS-16949, IATF-16949 |
| Environmental |
ISO-14001, REACH, RoHS |
| Transportation |
| Shipped |
@ 30% SOC |
| Part Number 300949-001 |
